FI002K0018v1530hUK – THS/21 Instruction manual for installation, use and maintenance

INSTALLAZIONE

ORIGINAL INSTRUCTION 109

SCN SCN Connections box

AM28 Ejection Confirmation sensor

AM14 Bin Full photocell

AM15 Pressure switch

AM29

Ejector position check

sensor

SM19

Bin lock connected to the

Emergency circuit

SM23

Bin absent/open sensor

connected to the Emergency

circuit

Y1 Ejector activation

Y2 Ejector deactivation

EM2 Emergency Button

Optional
