FI002K0018v1530hUK – THS/21 Instruction manual for installation, use and maintenance
DESCRIPTION
12 ORIGINAL INSTRUCTION
2.2 Metal detector
2.2.1 THS/21E and THS/21E-3F
The THS/21E is a high-sensitivity Metal Detector controlled by a microprocessor and designed for
industrial use. It is also available in an extremely compact version, the THS/SL21E (SLIM LINE
version), for mounting on a conveyor belt and is ideal for weighing machines.
The THS/21E-3F is a multi-frequency technology model, for use with a variety of products with
significant chemical-physical differences (dry, wet, frozen product, packed in metallized film). A slim
line version is also available: THS/SL21E-3F.
THS/21E
A
The Metal Detector Probe, complete with electronic control
unit (SCD)
B
The power supply box, for connecting the device to mains
power and to the external units (photocell, ejector, etc.).
C Connecting cable
D Tunnel
E
Stainless steel control panel fitted with alphanumeric display
and a 4-key programming keyboard
2.2.2 THS/21 and THS/MS21
The THS/21 is a very high-sensitivity Metal Detector controlled by a microprocessor and designed
for industrial applications processing dry products. It is also available in an extremely compact
version, the THS/SL21 (SLIM LINE version), for mounting on a conveyor belt and is ideal for weighing
machines.
The THS/MS21 is a multi-spectrum technology model, for use with a variety of products with
significant chemical-physical differences (dry, wet, frozen product, packed in metallized film). A slim
line version is also available: THS/SLMS21.
THS/21
A
The Metal Detector Probe, complete with electronic control
unit (SCD)
B
The power supply box, for connecting the device to mains
power and to the external units (photocell, ejector, etc.).
C
Connecting cable
D
Tunnel
E
Stainless steel control panel fitted with graphic display and a
16-key programming keyboard
