FI002K0018v1530hUK – THS/21 Instruction manual for installation, use and maintenance
DESCRIPTION
48 ORIGINAL INSTRUCTION
2.8 Technical characteristics
2.8.1 Metal Detector
General
characteristics
21 series 21E series
High-contrast OLED display Graphical, 128x64 pixels Alphanumeric, 4x20 chars
Programming keyboard, in stainless steel 4 keys 16 keys
Metal detection sensitivity High Very High
Display of the signal level by means of bar graph
Autolearn and automatic tracking of the product effect
Integrated self-diagnosis system to check, in real time, the System correct functioning
Up to 40 users, with username and password
Data management compliant with requirements indicated by CFR 21, Part 11
Complies with HACCP and GMP criteria
Metallic structures in AISI316. Parts in contact with the product in plastic materials, certified for food use,
according to FDA and USDA specifications
Power supply boxes available, on request, even in UL certificate version, according to UL 508A e CSA-
C22.2 No. 14-05 standards.
Programming Local Control panel
Remote By means of one of the available I/O interfaces and
CEIA THS Production, CEIA MDScope or another
equivalent terminal emulation software
Data storage 21 series 21E series
Max number of Products 500 250
Max number of Events 10.000
(100.000 with )
1.000
(100.000 with )
Events type Metal Alarm; Test results; Programming acces/exit;
Parameter modifications; Diagnosis messages;
Transport start/stop; Batch start/end
Data management Management of electronic production data and
electronic signatures compliant with the
requirements indicated by
CFR 21, Part 11
Data security
Data integrity
Data traceability
I/O interfaces RS232 and auxiliary RS232 serial ports Built-in (9600/57600 bps, 8N1 format)
BT Wireless interface Built-in (v2.1, Class 2)
Serial port for barcode reader Integrated (9600 bps, 8N1 format), enabled upon
request. Supported string formats:
xx<CR>; xx<LF>; <STX>xx<ETX>
xx: stringa di massimo 48 caratteri
Network card
(optional) with built-in
Web Server
Wi-Fi On USB key; Wireless standard: IEE 802.11 b/g/n;
Frequency: 2.400-2.4835 GHz; WPA2 security; Max
range: up to 20m in open areas, subject to limitations
Ethernet 2 ports 10/100 baseT; IP Protocol: static/DHCP
USB V2.0 (only for data storage on USB memory devices,
FAT32 formatted)
Field Bus Ethernet/IP (optional)
Signalling Acoustic internal built-in on or
Optical Control Panel display Visualization of messages and signal level
Control panel light
indicators
RED: Metal alarm or Diagnosis
GREEN: Power on
light indicators
WHITE: Power on
GREEN: Moving tansport
BLUE: Test request
Inputs / Outputs See description in sections 3.5.2 and 3.5.3
