Ceia THS/21 - Performing a Test in Standard Mode

FI002K0018v1530hUK – THS/21 Instruction manual for installation, use and maintenance
4
USE OF THE DEVICE
ORIGINAL INSTRUCTION 163
4.8.1.1 Performing a Test in standard mode
The procedure below describes a test with a ferrous sample; the other two samples, made from non-
ferrous metal and in stainless steel, follow the same procedure.
For the double and the triple test (see TMD on Programming Manual), the tests will be requested
one after the other.
The execution of the tests and the final response will be recorded in the event log.
THS/21E THS/21
To perform the Metal Detector test
(independently or in response to the
automatic request), access to
Programming, select MD Test > FE
test and press E key.
FE test -0.80 @
NFE test-1.00
SS test -1.20
FE~test~-0.80~~~~~~~@
NFE test-1.00
SS test -1.20
The customer is responsible for ensuring that the test samples are undamaged, clean, used correctly and are suitable
for the current product. The customer is responsible for following its own QA procedures
The test samples must be used only under the environmental conditions indicated as operative (see Technical
Characteristics) and in compliance with QA procedures.
Wait a few seconds, before
performing the sample transit.
=====================
WAIT
---------------------
[\\\\\\\\\\\\\\\\\\\]
WAIT
{|||||||||||||||||||}
Pass the test sample requested
together with the pure product,
through the detection probe within one
minute of the request (3 minutes with
Ejection Mode S or SB).
=====================
PASSE FE SAMPLE
---------------------
[\\\\\\\\\\\\\\\\\\\]
PASS FE SAMPLE
{|||||||||||||||||||}
If the sample is correctly detected and
the ejection system is correctly
activated, the test is successful.
=====================
TEST PASSED
---------------------
[
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
\
]
TEST PASSED
{|||||||||||||||||||}
Pressing any key, the display returns
to the MD test menu, where the
positive outcome is also shown.
FE test -0.80 OK
NFE test-1.00
SS test -1.20
FE~test~-0.80~~~~~OK
NFE test-1.00
SS test -1.20
The test is successful if all the test samples are detected (with an amplitude not higher than 12dB, according to the
predefined value set in the SAC parameter) and if the ejector has been correctly activated (i.e. the ejection
confirmation sensor has been triggered).
The operator is responsible for checking that the sample is correctly removed from the reject bin.
