2.3.1 Inverting component positions
2.3.1.1 Inverting the transit direction
It is possible, as an option at the order stage, to invert the transit direction, with respect to the
Detection Probe Control Panel.
From left to right
From right to left
Example with a THS-FBB
2.3.1.2 Inverting the ejection system position
It is also possible, as an option at the order stage, to invert the position of the ejection system as
shown in the figure below.
Ejection toward the front Ejection toward the back
Example with a THS-FBB
