3.11.4 Enabling an in-line device (i.e. upstream belt)
For systems with a Conveyor Control System, activation of the PREC_CONV relay coincides with
the belt movement.
Input Description Remote param. Values
PREC_CONV RELAY Belt in movement
PC
Activation (ON/OFF)
Conveyor Control System Waveform Description
Start Belt movement start button
Stop
Belt movement stop button or
fault/emergency condition
Conveyor belt Belt in movement
PREC_CONV RELAY -
