DESCRIPTION
ORIGINAL INSTRUCTION 29
2.4 Device identification
The ID plates here below are provided as examples only. The values shown vary from model to model.
2.4.1 Detection Probe
All Detection Probes, including those fitted to
integrated systems, have ID plates showing the
following data: Model and Serial number of the
detection Probe and Dimensions of the tunnel.
THS/MS21
31002xxxxxx
350 x 150
ID plate for a THS/MS21 Probe
2.4.2 Control Power Box
All control power boxes including those fitted to integrated system have ID plates with the information
shown in the examples below.
31002xxxxxx
100 – 240 Vac
50/60 Hz – 1ph
x kA rms Symmetrical
xx V max
XX,X A
IP65
THS/MS21-xxxxx
2017
E3xxx
THS/MS21
-
-
-
31002xxxxxx
100 – 120 Vac
50/60 Hz – 1ph
x kA rms
Symmetrical
xx V max
X.X A
IP65
4X
2017
E3xxx
ID plate for CE models ID plate for UL508A models
2.4.3 Conveyor Control System
31002xxxxxx
31002xxxxx
x
200 – 240 Vac
50/60 Hz – 1ph
x kA rms Symmetrical
xx V max
XX,X A
IP65
T/MS21-xxxxx/
FBB-1500x300xxx
2017
E3xxx
THS/MS21-THS-FBB
-
-
-
XX.X A
XXX Vac
XX Hp
31002xxxxxx
100 – 120 Vac
50/60 Hz – 1ph
5 kA rms
Symmetrical
240 V max
X.X A
IP65
4X
2017
E3xxx
ID plate for CE models ID plate for UL508A models
