3.9.5 Transit speed
The individual BS for each type of product is stored to memory and can be successively modified during the final
verifications with the product, performed in operative conditions.
3.9.5.1 Application with Control Power Box
These transit speed parameters set the speed of the product as it passes through the Detection
Probe. These values are used to define the ejection cycle.
Programming menu
Remote
parameter
Description Allowed values
Configuration(adv) > K transmiss
KT
Gear motor transmission
constant
0
Configuration(adv) > Min speed
BL
Minimum transit speed
1 ÷ BM m/min
Configuration(adv) > Speed
BS
*
Nominal transit speed
BL - BM m/min
Configuration(adv) > Max. speed
BM
Maximum transit speed
BL - 250 m/min
* Where an encoder is present (KE>0) this parameter is not available.
On systems with conveyor belt, it is recommended to use an encoder for the correct synchronization
of the ejector with the movement of the belt.
On free-falling applications, check that BS is set to a value equal or not lower than the expected
product transit speed at the Probe entrance, in order to guarantee an optimal detection and ejection
response from the System.
On applications with discontinuous transport (i.e. pumping of the product in a duct), set BS the
speed with active transport and consider the Metal Detector synchronization with the product
transport device (see Timings and Following Conveyor enabling).
Set BL and BM values as close as possible to BS, according to the specified settings, as this can increase the Metal
Detector immunity to interference.
3.9.5.2 Application with Conveyor Control System
These transit speed parameters set the speed of the conveyor belt. These values are used to
regulate conveyor movements and to define the ejection cycle.
Programming menu
Remote
parameter
Description Allowed values
Configuration(adv) > K transmiss
KT
Gear motor transmission
constant
See procedure for the
motor connection
Configuration(adv) > Min speed
BL
Minimum transport speed
10 x KT - BM m/min
Configuration(adv) > Speed
BS
*
Transport speed
BL - BM m/min
Configuration(adv) > Max. speed
BM
Maximum transport speed
BL - MI x KT m/min
Configuration(adv) > Max inv.freq.
MI
Maximum inverter frequency
60 - 100 Hz
* Where an encoder is present (KE>0) this parameter is not available.
By modifying the value of KT, the parameters BL and BM are automatically set to nominal values, respectively 30 x KT
and 60 x KT. BL and BM can also be modified manually. The value set on BS can be successively modified also through
the proper keys on Conveyor Control System panel.
In presence of an encoder, the parameter BS is always available, but the ejection cycle is determined according to the
speed measured by the encoder itself (see Timings).
Set BL and BM values as close as possible to BS, according to the specified settings, as this can increase the Metal
Detector immunity to interference.
