Ceia THS/21 - Integrated System Technical Specifications

2
FI002K0018v1530hUK – THS/21 Instruction manual for installation, use and maintenance
DESCRIPTION
50 ORIGINAL INSTRUCTION
2.8.2 Integrated systems
General
characteristics
Conveyor belt with integrated THS/21x Metal Detector and ejection system
HACCP compliant
Metallic structures in AISI316. Parts in contact with the product in plastic materials, certified for food use,
according to FDA and USDA specifications
Conveyor Control System also available in UL certificate version, compliant with UL 508A and
CSA-C22.2 No. 14-05 standards
Conveyor belt
THS-FBB THS-MBB THS-MBR
THS-FBV
THS-FBBV
THS-RB
THS-RBK
Belt type
flat
(PU)
modular
(PE)
modular
(PE)
flat
(PU)
round belt
(PU)
Speed range (m/min)
14

60
8

40
12

55 12

45
20

60
14

60
14

80
Distributed max load (kg) 40 40 40 40 2
Pack max
1
weight (kg) with air
blow ejection system
1 1 1
Pack max
1
weight (kg) with piston
ejection system
4 4 4
Pack max
1
weight (kg) with bridge
ejection system
10 10
Maximum load of the reject bin indicated on the System reject bin
Sensors Standard Ejection synchronization; Ejection confirmation (only with ejector)
Optional
(according to the model)
Ejection verification; Low pressure, Ejector position check, Bin full,
Bin absent, Encoder
Safety functions Conveyor belt stop
Cat.0 (EN60201-1)
PL (Performance Level): c
(EN ISO 13849-1)
Pneumatic actuator stop
Programming Local Control panel
Remote
By means of one of the available I/O interfaces and CEIA THS
Production, CEIA MDScope or another equivalent terminal
emulation software
Signalling Acoustic internal built-in on or
external
built-in on external beacon
standard: adjustable, 94 dB max
IP69K (optional): fixed 65 db
Optical Control Panel
display
Visualization of messages and signal level
Control panel light
indicators
RED: Metal alarm or Diagnosis
GREEN: Power on
light indicators
WHITE: Power on
GREEN: Moving tansport
BLUE: Test request
Inputs / Outputs See description in sections 3.5.2 and 3.5.3
Electric supply 115V 230V
Mains voltage 100÷120 Vac 200÷240 Vac
Mains frequency 50/60Hz single phase 50/60Hz single phase
Full load current (FLA)
11.2 A
(15 A with THS/MN21)
11.4 A
(15 A with THS/MN21)
Short-circuit maximum current 5 kA (symmetric, 240 V max) on connection point
Power supply impedance

0,40

, on connection point
Distribution system TN (for other systems, contact CEIA)
Pneumatic supply Piston ejector Air blow ejector
Air pressure 0.6÷1 Mpa 0.6÷1 Mpa
Air flow 100 Nl/min 600 Nl/min
1
The maximum weight may vary according to the product package characteristics
