DESCRIPTION
ORIGINAL INSTRUCTION 49
Supply Control Power Box Main voltage 100-240 VAC
Frequency and phase 50/60 Hz - single phase
Full load current (FLA) 2.2 A (6.6 A for THS/MN21)
Short-circuit maximum current 5 kA (symmetric, 240 V max)
Conveyor Control System
Main voltage
115V version: 100÷120 VAC
230V version: 200÷240 VAC
Frequency 50/60 Hz - single phase
Full load current (FLA)
115V version: 11.2 A
(15 A for THS/MN21)
230V version: 11.4 A
(15 A for THS/MN21)
Short-circuit current 5 kA (simmetrica, 240 V max)
Maximum power of the three-
phase pilotable motor
115V version: 0.37 kW (0.5 hp)
230V version: 0.75 kW (1 hp)
Small-size power supply
card
Power supply voltage 20÷30 Vdc o Vac; 2A max.
Protection degree 21 series
IP66 – IP69K
On UL versions, the and
have a type 4X-12 certified
degree of protection
21E series
IP65
Dimensions and
Weights
Useful and overall dimensions See related section
Useful cable length
Power supply not included
Probe connection
2 m (custom lengths up to 40 m,
on request)
Weight
With package Indicated outside the package
Net
Indicated on FAT document,
enclosed with the System
Environmental
conditions
Use
Indoor. Industrial environment. NOT SUITABLE for use in presence
of a potentially flammable or explosive atmosphere
Temperature
Operating -10°C

+55°C
Storage
-40°C

+70°C* - for short
periods, not more than 24h
Relative humidity
Operating 5%

90%, non-condensing
Storage
5%

90%, non-condensing
Altitude

1000m, without derating.
For higher altitudes, contact CEIA
Pollution degree (IEC61010-1) Class 2
Installation category (IEC61010-1) Category II
