DESCRIPTION
30 ORIGINAL INSTRUCTION
2.4.4 CEIA conveyor structure
CEIA integrated systems have an additional ID plate
for the conveyor belt as shown in the example here.
THS-FBB
31002xxxxxx
1500 x 300
2.5 Functional diagrams
Legend
CEIA INDUSTRIAL
METAL DETECTOR
INCLUDED
COMPONENT
OPTIONAL
COMPONENT
EXTERNAL DEVICE
OR CONNECTION
2.5.1 THS with Control Power Box
