FI002K0018v1530hUK – THS/21 Instruction manual for installation, use and maintenance
MAINTENANCE
176 ORIGINAL INSTRUCTION
5.2.3.4 THS-RB
Remove the four locking pins Lift up the belt block from its housing Remove the belt block from the detection
tunnel
Follow the procedure in reverse to re-assembly the conveyor belt.
Pay attention to the hands during the placement of the belt block, in order to avoid the risk of shearing between the belt
block and the belt frame.
