Ceia THS/21 - Page 164

4
FI002K0018v1530hUK – THS/21 Instruction manual for installation, use and maintenance
USE OF THE DEVICE
164 ORIGINAL INSTRUCTION
If the test is unsuccessful, one of the following messages will be seen:
TEST FAILED for Sample not detected
THS/21E THS/21
If the sample is not detected it could
be that the transit was performed in
the 20 seconds immediately after the
request, or the sample signal is lower
than the alarm threshold.
=====================
TEST FE FAILED
NO SAMPLE DETECTED
---------------------
[\\\\\\\\\\\\\\\\\\\]
TEST FE FAILED
NO SAMPLE DETECTED
{|||||||||||||||||||}
Pressing any key, the display returns
to the MD test menu, where the
negative outcome is also shown.
FE test -0.80 NO(1)@
NFE test-1.00
SS test -1.20
1- NO SAMPLE DETECTED
FE~Test~-0.80~~NO(1)@
NFE Test-1.00
SS test -1.20
1- NO SAMPLE DETECTED
TEST FAILED for Sample too big
THS/21E THS/21
The signal given by the sample is
considered too high to perform a valid
test, according to the maximum
allowed level (see Q.C.setup menu).
=====================
TEST FE FAILED
SAMPLE TOO BIG
---------------------
[\\\\\\\\\\\\\\\\\\\]
TEST FE FAILED
SAMPLE TOO BIG
{|||||||||||||||||||}
Pressing any key, the display returns
to the MD test menu, where the
negative outcome is also shown.
FE test -0.80 NO(2)@
NFE test-1.00
SS test -1.20
2- SAMPLE TOO BIG
FE~Test~-0.80~~NO(2)@
NFE Test-1.00
SS test -1.20
2- SAMPLE TOO BIG
TEST FAILED for Ejection not confirmed
THS/21E THS/21
If the sample is correctly detected, but
there is not any confirmation of its
ejection, the test is considered to be
unsuccessful.
=====================
TEST FE FAILED
EJECT.NOT CONFIRM
---------------------
[\\\\\\\\\\\\\\\\\\\]
TEST FE FAILED
EJECT.NOT CONFIRM
{|||||||||||||||||||}
Pressing any key, the display returns
to the MD test menu, where the
negative outcome is also shown.
FE test -0.80 NO(3)@
NFE test-1.00
SS test -1.20
3- EJECT.NOT CONFIRM
FE
~
T
es
t
~-
0
.
80
~~
NO(3)
@
NFE Test-1.00
SS test -1.20
3- EJECT.NOT CONFIRM
