8.2.8 Coil spring
Removal
Schematic diagram
Steps
1 - Rear axle; 2-Jack
1. Raise the vehicle.
2. Remove the rear wheel.
3. Support the rear axle with a jack to
prevent it from falling.
1
-Lateral thrust rod; 2-Right mounting bolt
4. Remove the right mounting bolt and nut
of the lateral thrust rod.
1-E-ring
5. Remove the E-ring of the brake hose.
