Steering system
218
10.2.2 Tightening torque specification
Fastener
Tightening torque
N·m
kg·m
ft-lbs
Steering shaft joint bolt
25
2.5
18.0
Steering gear housing bolt
25
2.5
18.0
Upper bracket bolt
25
2.5
18.0
Steering tie rod joint slotted nut
43
4.3
31.5
Steering tie rod joint lock nut
45
4.5
32.5
Steering pinion bearing screw plug
95
9.5
69.0
Steering tie rod
85
8.5
61.5
Wheel nut
75
7.5
54.5
10.2.3 Necessary maintenance materials
Materials
Purpose
Lithium lubricating grease (suitable
for -40℃~130℃)
Slide the rack against the steering housing
(including the plunger, rack bushing, and rack)
Slide the parts against the steering pinion (oil
seal lip, needle bearing)
The teeth of the steering rack and pinion fill the
inside of the steering pinion bearing
Steering tie rod and rack dust cover internal
connecting components, rack end ball joint
Anti loosening adhesive
Steering pinion bearing bolt thread
