CENNTRO LOGISTAR 100 - Front Door Assembly

Exterior trims
27
3.2.2 Front door assembly
Removal
Schematic diagram
Steps
1. Remove the front fender flap.
2. Disconnect the door harness connector
and remove the corrugated pipe from the
vehicle body.
1 - Door opening limiter; 2-Pin
3. Remove the limiter connecting pin by
gently tapping it upwards with a hammer.
