Air conditioning control system
11.4.2 The motor and fan assembly
Removal and installation
1. Remove the air heater assembly.
2. Unscrew the fixing screws and remove
the motor and fan assembly-1-.
1. The installation sequence is the reverse
of the removal sequence.
11.4.3 Speed regulating resistor
Removal and installation
1. Disconnect the negative battery cable.
2. Disconnect the connection plug of the
speed regulating resistor.
3. Unscrew the fixing screws and remove
the speed regulating resistor-1-.
1. The installation sequence is the reverse
of the removal sequence.
