Lighting system
13.1.2 Headlamp
① Headlamp
A reflecting mirror. Adjust the alignment of
the light beam by adjusting the reflecting
mirror.
② Headlamp adjustment
To be determined after testing
If the lamp housing, light distribution mirror, reflecting mirror, mounting leg, etc. are
broken or leaking, replace the lamp.
③ Automatic headlamp
The controller controls the low beam headlamp on and off based on the light sensor
signal.
(1) Component location
