CENNTRO LOGISTAR 100 - Front Bumper Air Inlet Grille

Exterior trims
61
3.8.2 Front bumper air inlet grille
Removal and installation
Schematic diagram
Removal steps
1. Open the front cabin cover and remove
the screws at the positions shown (as
indicated by the arrows) in the figure.
△
! Description
The disassembly sequence is from
bottom to top.
2. Remove the front bumper air inlet grille
from the front bumper.
Installation steps
1. Install the front bumper air inlet grille in
the reverse order of removal.
