Steering system
222
10.2.7 Inspection of steering tie rod ball pin dust cover
Schematic diagram
Steps
1. Check each dust cover for tears.
2. If any tear is found, replace it with a
new dust cover.
10.2.8 Inspection of steering shaft universal joint
Schematic diagram
Steps
1. Check the steering shaft joint for wear,
cracks, and other faults.
2. If any problem is found, replace it.
10.2.9 Inspection of steering tie rod ball pin
Schematic diagram
Steps
1. Check the play of the ball pin.
2. Check the play of the rack end ball pin.
3. If any undesirable play is found, replace
it again.
