Exterior trims

3.7.2 Windshield wiper

Check the wiper/cleaner switch

Schematic diagram

Steps

1 - Battery; 2-Wiper motor; 3-Red conductor ;

4-Black conductor

1. Disconnect the spiral harness and

combination switch harness connector.

2. Use a multimeter to check the

continuity between each terminal.
