Exterior trims
38
3.3.2 Adjustment of the front cabin cover
Schematic diagram
Steps
1 - Front cabin cover cushion; 2-Glass
cleaning hose
1. Front, rear, left, right adjustment
• Loosen four assembly fasteners of the
front cabin cover and make adjustment.
2. Vertical adjustment
• If only one side of the front cabin cover
(right and left) is not level with respect to
the fender flap, tighten or loosen the front
cabin cover cushion to make it level.
3.3.3 Adjustment of the front cabin cover lock
Schematic diagram
Steps
1. Loosen the fasteners of the front cabin
cover lock (a) and make adjustment.
2. After adjustment, tighten the fasteners
of the front cabin cover lock (a).
Tightening torque: 10N·m
(1.0kg·m,7.5ft-lbs)
