CENNTRO LOGISTAR 100 - Rebound Stopper and Upper Spring Seat

8.2.7 Rebound stopper and upper spring seat
Removal and installation
Schematic diagram
Removal steps
1-Upper spring seat; 2-Rebound stopper
1. Remove the coil spring.
2. Remove the upper spring seat.
3. Remove the rebound stopper.
/
Installation steps
1-Upper spring seat; 2-Rebound stopper
1. Install the rebound stopper.
△! Caution
Before installing the bushing tightly,
apply soapy water to the bushing.
2. Install the upper spring seat. Refer to
the figure for the correct installation
direction of the upper spring seat.
3. Install the coil spring.
