CENNTRO LOGISTAR 100 - Power Window Auxiliary Switch; Power Window Main Switch

Exterior trims
35
3.2.7 Power window auxiliary switch
Schematic diagram
Steps
1. Check the conductance between the
switch wiring ends.
3.2.8 Power window main switch
Schematic diagram
1 - Power window main switch; 2 – Power
window lock switch;
3 - Driver window switch; 4 – Front passenger
window switch.
Open
Down
Close
Wiring end
Switch position
Open
Window lock switch power supply
Close
Up
Close
Down
Up
Close
Down
Driver window
switch
Front passenger
window switch
