CENNTRO LOGISTAR 100 - Air Heater

Air conditioning control system
257
11.3.4 Air heater
Removal and installation
Schematic diagram
Removal steps
1. Remove the air heater.
2. Unscrew the fixing screws and remove
the motor and fan assembly.
3. Unscrew the fixing screws and remove
the speed regulating resistor.
4. Remove the fixing clip from the air
heater housing.
