Vehicle body

2.2 Fender flap

2.2.1 Front fender flap

Removal

Schematic diagram

Steps

1 - Front fender flap; 2-Front fender flap lining plate;

3 - Side turn signal lamp connector

1. Disconnect the negative cable

of the low voltage battery.

2. Remove the front bumper.

3. Disconnect the harness

connector of the side turn (side

marker) lamp.

4. Remove the front fender flap

lining plate.

5. Remove the front fender flap.

Installation

Install the front fender flap in the reverse order of removal.
