Exterior trims

3.2.3 Front door glass lifter assembly

Removal

Schematic diagram

Steps

1 - Glass lifter assembly; 2-Glass lifter bolt;

3-Door glass mounting screw

1. Remove the front door glass.

2. Disconnect the harness connector of

the electric motor for the power window

and release the wire clip (if equipped).

3. Remove fixing bolts of the glass lifter

and take out the glass lifter through the

hole.
