CENNTRO LOGISTAR 100 - Instrument Panel

Interior trim
66
(b):23N·m(2.3kg·m,
17.0ft-lbs)
23
Slide rail assembly-left
24
Slide rail unlocking
handle
25
Lower slide rail
mounting nut M8
26
Base assembly - right
27
Base assembly - left
28
Front safety belt
buckle
4.3 Instrument panel
4.3.1 Console, instrument panel, and steering support beam
Schematic diagram
Removal steps
1. Remove the shock pad of the tea cup
and the front cover plate of the hand brake.
2. Remove one console mounting screw
and two console mounting clips, and
remove the console.
