CENNTRO LOGISTAR 100 - Front Crossbeam Assembly

Vehicle body
18
2.1.2 Front crossbeam assembly
Removal
Schematic diagram
Steps
1. Disconnect the negative cable of the
low voltage battery.
2. Disconnect the power battery.
3. Remove the front bumper.
4. Remove the pedestrian friendly
reminder module.
5. Remove the condenser.
6. Remove the drive motor grounding wire
fastener (A).
7. Remove the drive motor front
suspension bracket fasteners (B).
8. Raise the vehicle.
9. Remove the drive motor lower guard.
10. Remove the drive motor support
crossbeam.
11. Remove 8 fasteners of the left and right
thrust rods.
12. Remove the left and right thrust rods.
