Air conditioning system
137
1
- Shock absorber; 2-Rear axle; 3 - Lower
mounting bolt
3. Install the rear shock absorber onto the
rear axle.
4. Remove the jack from the rear axle.
5. Install the wheel and tighten the wheel
nuts to the specified torque.
Tightening torque:
(a):85N·m(8.5kg·m,61.5ft-lbs)
1 - Rear trailing arm; 2-Shock absorber
6. Lower the jack and tighten the front and
rear mounting nuts of the rear trailing arm
and the lower mounting bolts of the shock
absorber with the specified torque when the
vehicle is in an unloaded state.
Tightening torque: (b):80N·m(8.0kg·m,
58.0ft-lbs)
(c):80N·m(8.0kg·m, 58.0ft-lbs)
(d):58N·m(5.8kg·m, 42.0ft-lbs)
