CENNTRO LOGISTAR 100 - Page 277

Air conditioning control system
263
4. Remove the evaporator assembly cover
and remove the evaporator core - 1 - in the
direction of the arrow.
5. Remove the evaporator temperature
sensor - 1 - from the evaporator core - 2 -.
Installation steps
1. The installation sequence is the reverse
of the removal sequence.
