Air conditioning control system
279
6. Unscrew the fixing bolts and remove
the condenser outlet pipe 2 # assembly - 1
-.
Installation steps
1. The installation sequence is the reverse
of the removal sequence, noting the
following:
△
! Tips:
Fill the air conditioning refrigerant into
the air conditioning refrigerant charging
and discharging machine.
Check the air tightness of the
refrigerant circulation circuit.
