Interior trim
15. Remove the instrument panel (5 fixing
bolts to the vehicle body and 6 fixing bolts
to the steering support beam) and
disconnect the hazard warning lamp switch.
16. Remove the steering support beam (4
steering column nuts, 2 steering column
bolts, 1 steering support beam mounting
bolt, and 4 Ecall mounting bolts).
1. Install the console, instrument panel,
and steering crossbeam in the reverse order
of removal.
