Programmable DC Power Supply (with Solar Array Simulation) 62000H Series
Operating & Programming Manual
Figure 3-112
7. Once the 1.5A point is calibrated, it is important to turn the loading from the Electronic
Load off and reconnect the DC Power Supply to a current shunt whose rating is closest to
but still covers 2A. For the Prodigit 7550, use the 2A shunt directly.
8. Next, press “ ” to do the 4.5A calibration. The cursor will stop at position [2] as
shown in Figure 3-113 for setting the loading current of the Electronic LOAD to 4.500A.
Enter the current read by the Current Shunt (DVM) and press “ ” to confirm and
wait for it to end. Use 1.5A and 4.5A for calibration; the system will calculate the
calibration factor for the low current range.
Figure 3-113
9. After the low current range is calibrated, it is important to turn the loading from the
Electronic Load off and reconnect the DC Power Supply to a current shunt whose rating
is closest to but still covers 20A. For the Prodigit 7550, use the 20A shunt directly.
10. For the high current range calibration, press “ ” to perform the 7.5A calibration.
The cursor will stop at position [3] as shown in Figure 3-114 for setting the loading current
of the Electronic LOAD to 7.500A. Enter the current read by the Current Shunt (DVM)
and press “ ” to confirm and wait for it to end.
Figure 3-114
[ C U R R E N T M E A S C A L I B R A T I O N ]
A P P L Y L O A D I N G A N D P R E S S [
E N T E R ]
S E T L O A D I N G C U R R E N T
= 1 . 5 0 0 A
A C T U A L O U T P U T C U R R E N T
=
0 . 0 0 0 0 _ A
[
1 ]
[ C U R R E N T M E A S C A L I B R A T I O N ]
S E T L O A D I N G C U R R E N T = 4
. 5 0 0 A
A C T U A L O U T P U T C U R R E N T = 0 . 0 0 0 0 _ A
[ 2 ]
[ C U R R E N T M E A S C A L I B R A T I O N ]
S E T L O A D I N G C U R R E N T = 7 . 5 0 0 A
A C T U A L O U T P U T C U R R E N T = 0 .
0 0 0 0 _ A
[ 3 ]
