Program Sequence
4-11
[ S E Q U E N C E ]
S E Q N O
= 1
S E Q T Y P E
= A U T O
_
T I M E
= 0 . 0 0 0 ( S )
V O L T A G E = 0 .
0 0
V
V S . R . = 1 . 0 0 0 ( V/ m s
)
C U R R E N T = 0 . 0 0 0 A
I
S . R . = I N F . ( A / m s ) ▲
▼
Figure 4-9
Ex. 5: Set Sequence Type to AUTO
If PROGRAM 1 is set as shown in Figure 4-10, the output load is 10(Ω).
[ PROGRAM
]
PROG NO.
= 1
RUN COUNT = 2
PROG CHAIN
= NO
CLEAR PROG
= NO
[ SEQUENCE ]
SEQ NO.
= 1
SEQ TYPE
= AUTO TIME = 5.000(S)
VOLTAGE
= 10.00V
V S. R. = 1.000(V/ms)
CURRENT
= 20.000A
I S. R.
= 1.000 (A/ms)
[ SEQUENCE ]
SEQ NO.
= 2
SEQ TYPE
= AUTO TIME = 10.000(S)
VOLTAGE
= 30.00V
V S. R. = 10.000(V/ms)
CURRENT
= 20.000A
I S. R.
= 1.000 (A/ms)
[ SEQUENCE ]
SEQ NO.
= 3
SEQ TYPE
= AUTO TIME = 0.000(S)
VOLTAGE
= 0.00V
V S. R. = 1.000(V/ms)
CURRENT
= 0.000A
I S. R.
= 1.000(A/ms)
↓
↓
↓
[ SEQUENCE ]
SEQ NO.
= 10
SEQ TYPE
= AUTO TIME = 0.000(S)
VOLTAGE
= 0.00V
V S. R. = 1.000(V/ms)
CURRENT
= 0.000A
I S. R.
= INF. (A/ms)
EXT._TRIG PULL = HIGH
Figure 4-10
