5.5.3.7.- Datalogger expansion modules
The screen in Figure 108 display screen, is a screen that displays the information of the
Datalogger communications module.
Figure 108: Datalogger (TCP) module information screen.
This screen shows how the TCP communications of the module are congured.
The following options appear in the lower area:
TCP, for viewing how the TCP communications have been congured.
Port, for viewing how the port have been congured..
Back, returns to the expansion module information screen, Figure 98
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
On selecting the Port option, , the screen in Figure 109, appears with information on the
port number, Embedded version and Power Studio version.
121
Instruction Manual
CVM-B100 - CVM-B150
