6.3.7.9.- Installation data
These parameters occupy 1 register each.
Table 40: Modbus memory map: Conguration variables (Installation data)
Installation data
Configuration variable Address Valid data window Default value
Nominal Frequency
(1)
2720 5000 or 6000 5000
Number of quadrants 2722 2 or 4 4
(1)
The units of the frequency are at address 0x157F. Format of the units: Power of 10 (with sign).
6.3.7.10.- Cost of energy consumption and generation
The Cost conguration variables occupy 2 registers each.
The Currency conguration variables occupy 4 registers.
Table 41:Modbus memory map: Conguration variables (Energy cost)
Energy cost
Configuration variable Address Valid data window Default value
Cost per kWh of tariff 1 consumption 27D8-27D9 0 to 100
(1)
0
Cost per kWh of tariff 2 consumption 27DA-27DB 0 to 100
(1)
0
Cost per kWh of tariff 3 consumption 27DC-27DD 0 to 100
(1)
0
Cost per kWh of tariff 1 generation 27DE-27DF 0 to 100
(1)
0
Cost per kWh of tariff 2 generation 27E0-27E1 0 to 100
(1)
0
Cost per kWh of tariff 3 generation 27E2-27E3 0 to 100
(1)
0
Currency 27E4-27E7 7 ascii characters EURO
(1)
The number of decimals are indicated at address 0x1586. Format of the units: Power of 10 (with sign).
Note: The 16 registers must be written and read at once (as a group), otherwise it will respond
with an error.
6.3.7.11.- CO
2
consumption and generation emissions
These parameters occupy 2 registers each.
Table 42:Modbus memory map: Conguration variables (CO
2
emissions)
C0
2
emissions
Configuration variable Address Valid data window Default value
Tariff 1 consumption emissions ratio 2774-2775 0 to 100
(1)
0
Tariff 2 consumption emissions ratio 2776-2777 0 to 100
(1)
0
Tariff 3 consumption emissions ratio 2778-2779 0 to 100
(1)
0
Tariff 1 generation emissions ratio 277A-277B 0 to 100
(1)
0
Tariff 2 generation emissions ratio 277C-277D 0 to 100
(1)
0
Tariff 3 generation emissions ratio 277E-277F 0 to 100
(1)
0
(1)
The number of decimals are indicated at address 0x1585. Format of the units: Power of 10 (with sign).
Note: The 12 registers must be written at once (as a group), otherwise it will respond with an
error.
192
CVM-B100 - CVM-B150
Instruction Manual
