● When programming the scale:
0... 20mA, to select the scale from 0 to 20mA.
4... 20mA, to select the scale from 4 to 20mA.
0... 10V, to select the scale from 0 to 10V.
Previous, selects the previous parameter.
Next, selects the next parameter.
Conrm, conrms and saves in the memory the values programmed on the screen.
Back, returns to the home screen of the analogue inputs menu Figure 176.
Main Menu, back to the main menu, Figure 25.
● When programming the Zero and the Full-scale value:
Zero is the value for which you have the start of the analogue output, 0 or 4mA.
The Full-scale is the value for which you have the end of the analogue output, 20mA.
, ... the ten possible digits to program.
Negative, the minus sign.
Comma, the comma.
Delete character, deletes the selected character.
Delete parameter, deletes the characters of the selected parameter.
Previous, selects the previous parameter.
Next, selects the next parameter.
Conrm, conrms and saves in the memory the values programmed on the screen.
Back, returns to the home screen of the analogue inputs menu Figure 176.
Main Menu, back to the main menu, Figure 25.
Zero Value:
Maximum and Minimum value:
Table 22
Full-scale:
Maximum and Minimum value: Table 22
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
253
Instruction Manual
CVM-B100 - CVM-B150
