Next, selects the next parameter.
Conrm, conrms and saves in the memory the values programmed on the screen.
Back, returns to the main conguration screen for analogue inputs, Figure 174.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
7.4.3.2.-
Analogue outputs.
Select the output to congure on the main conguration screen for the analogue outputs,
Figure 176.
Figure 176: Main conguration screen for analogue outputs.
The following options appear in the lower area:
... Analogue outputs, 1 to 8, to select the conguration of each of the 8 ana-
logue outputs.
Back, returns to the main conguration screen for analogue inputs/outputs,
Figure 173.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
