Conrm, conrms and saves in the memory the values programmed on the screen.
Back, returns to the main conguration screen for analogue inputs, Figure 174.
Main Menu, back to the main menu, Figure 25.
Zero Value:
Maximum value: 32000.
Minimum value: -32000.
Full-scale:
Maximum value: 32000.
Minimum value: -32000.
● When programming the Decimal position:
Here you program the number of decimals that the digital input will have.
, ... The number of possible decimals to program.
Delete character, deletes the selected character.
Delete parameter, deletes the characters of the selected parameter.
Previous, selects the previous parameter.
Next, selects the next parameter.
Conrm, conrms and saves in the memory the values programmed on the screen.
Back, returns to the main conguration screen for analogue inputs,Figure 174.
Main Menu, back to the main menu, Figure 25.
Decimal position:
Maximum value: 5.
Minimum value: 0.
● When programming the analogue input name and the units:
Here you enter the name for recognising the analogue input (maximum of 8 characters) and
the units it will have.
, ... the possible letters to program.
, ... the ten possible digits to program.
Delete character, deletes the selected character.
Delete parameter, deletes the characters of the selected parameter.
Previous, selects the previous parameter.
250
CVM-B100 - CVM-B150
Instruction Manual
