Figure 217: Main screen of expansion modules.
Displayed here are all the expansion modules connected to the unit.
If in the unit there is more than one module of the same type connected, a number will appear
in the icon to differentiate them
; the module with the lowest number has the lowest serial
number.
Use the
and buttons to move to the different options and select the Modbus TCP
(Switch) communications
icon.
Press the button
to open the main configuration screen of the Modbus TCP
communications module,
Figure 218.
Figure 218: Main conguration screen of the Modbus TCP communications module.
The following options appear in the lower area:
306
CVM-B100 - CVM-B150
Instruction Manual
