To select a parameter, press the button to open the menu at the bottom for selecting the
phase:
For the Neutral-Phase and
Voltage parameters:
Phase L1, Phase L2, Phase L3, Three-phase, Neutral.
For the Phase-Phase Voltage
parameter:
Phase L1-L2, Phase L2-L3, Phase L1-L3, Phase L1-L2-L3.
For the Frequency parameter:
Phase L1.
For the Active power, Inductive reactive power, Capacitive reactive power, Total
reactive power, Apparent power, Power factor and Cosine phi parameters:
Phase L1, Phase L2, Phase L3, Three-phase.
For the Voltage THD and Current THD parameters:
Phase L1, Phase L2, Phase L3, Neutral.
The option appears after selecting the phase to save the selection.
The following options are also shown on the bottom at all times
Back, returns to the previous customisation screen.
Main Menu, back to the main menu, Figure 25.
Use the keys and to browse the different options.
To access the option selected press the key
.
59
