1-81
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring IP Unicast Routing
Configuring Multi-VRF CE
Use the no ip vrf vrf-name global configuration command to delete a VRF and to remove all interfaces
from it. Use the no ip vrf forwarding interface configuration command to remove an interface from the
VRF.
Configuring VRF-Aware Services
IP services can be configured on global interfaces, and these services run within the global routing
instance. IP services are enhanced to run on multiple routing instances; they are VRF-aware. Any
configured VRF in the system can be specified for a VRF-aware service.
VRF-Aware services are implemented in platform-independent modules. VRF means multiple routing
instances in Cisco IOS. Each platform has its own limit on the number of VRFs it supports.
VRF-aware services have the following characteristics:
The user can ping a host in a user-specified VRF.
ARP entries are learned in separate VRFs. The user can display Address Resolution Protocol (ARP)
entries for specific VRFs.
These services are VRF-Aware:
ARP
Ping
Simple Network Management Protocol (SNMP)
Hot Standby Router Protocol (HSRP)
Unicast Reverse Path Forwarding (uRPF)
Syslog
Traceroute
FTP and TFTP
Note The switch does not support VRF-aware services for Unicast Reverse Path Forwarding (uRPF) or
Network Time Protocol (NTP).
User Interface for ARP
Beginning in privileged EXEC mode, follow these steps to configure VRF-aware services for ARP. For
complete syntax and usage information for the commands, refer to the switch command reference for
this release and the Cisco IOS Switching Services Command Reference, Release 12.4.
Step 10
show ip vrf [brief | detail | interfaces]
[vrf-name]
Verify the configuration. Display information about the configured
VRFs.
Step 11
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Command Purpose
show ip arp vrf vrf-name Display the ARP table in the specified VRF.
