Chapter 1 Assigning the Switch IP Address and Default Gateway
Boot Loader Upgrade and Image Verification for the FIPS Mode of Operation
The following table describes upgrade and downgrade scenarios using different images and using the
FIPS mode or non-FIPS mode:
Table 1-6 Upgrade and Downgrade Scenarios Relating to FIPS Certified Images
Upgrade/ Downgrade Scenario Action Status or Result
Upgrade from an image that is in
the FIPS mode to a Cisco IOS
Release 15.0(2)SE1 image in the
FIPS mode.
Boot with the Cisco IOS Release
15.0(2)SE1 image.
• The boot loader is upgraded.
• The image signature is verified.
• The following message appears in the boot
sequence: “Image passed digital signature
verification.”
Note If you upload a corrupt or unsigned
image, the following message appears
during boot up: “Image verification
failed.”
Upgrade from a switch that is in
the non-FIPS mode to a Cisco IOS
Release 15.0(2)SE1 image in the
FIPS mode.
• Configure the fips authoriza-
tion-key authorization-key global
configuration command.
• Reload the switch for the FIPS key
to be operational. By default, the
switch automatically boots up;
however, if you have configured it
to boot up manually, you have to
initiate the reboot.
• After the boot loader is upgraded,
boot with the Cisco IOS Release
15.0(2)SE1 image.
• The boot loader is upgraded.
• The image signature is verified.
Note If you upload a corrupt or unsigned
image, the following message appears
during boot up: “Image verification
failed.”
Upgrade to Cisco IOS Release
15.0(2)SE1 in the non-FIPS mode.
Boot with the Cisco IOS Release
15.0(2)SE1 image.
• The boot loader is not updated.
• The image signature is not verified.
• The switch works normally.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
