1-3
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring Online Diagnostics
Configuring Online Diagnostics
By default, health monitoring is disabled, but the switch generates a syslog message when a test fails.
Beginning in privileged EXEC mode, follow these steps to configure and enable the health-monitoring
diagnostic tests:
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
diagnostic monitor interval switch
number test {name | test-id |
test-id-range | all} hh:mm:ss
milliseconds day
Configure the health-monitoring interval of the specified tests.
The switch number keyword is supported only on Catalyst 3750-X
switches. The range is from 1 to 9.
When specifying the tests, use one of these parameters:
• name—Name of the test that appears in the show diagnostic content
command output.
• test-id—ID number of the test that appears in the show diagnostic
content command output.
• test-id-range—ID numbers of the tests that appear in the show
diagnostic content command output.
• all—All of the diagnostic tests.
When specifying the interval, set these parameters:
• hh:mm:ss—Monitoring interval in hours, minutes, and seconds. The
range for hh is 0 to 24, and the range for mm and ss is 0 to 60.
• milliseconds—Monitoring interval in milliseconds (ms). The range is
from 0 to 999.
• day—Monitoring interval in the number of days. The range is from 0
to 20.
Step 3
diagnostic monitor syslog (Optional) Configure the switch to generate a syslog message when a
health-monitoring test fails.
Step 4
diagnostic monitor threshold switch
number test {name | test-id |
test-id-range | all} failure count count
(Optional) Set the failure threshold for the health-monitoring tests.
The switch number keyword is supported only on Catalyst 3750-X
switches. The range is from 1 to 9.
When specifying the tests, use one of these parameters:
• name—Name of the test that appears in the show diagnostic content
command output.
• test-id—ID number of the test that appears in the show diagnostic
content command output.
• test-id-range—ID numbers of the tests that appear in the show
diagnostic content command output.
• all—All of the diagnostic tests.
The range for the failure threshold count is 0 to 99.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
