1-33
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring Interface Characteristics
Configuring Ethernet Interfaces
Use the no speed and no duplex interface configuration commands to return the interface to the default
speed and duplex settings (autonegotiate). To return all interface settings to the defaults, use the default
interface interface-id interface configuration command.
This example shows how to set the interface speed to 100 Mb/s and the duplex mode to half on a
10/100/1000 Mb/s port:
Switch# configure terminal
Switch(config)# interface gigabitethernet1/0/3
Switch(config-if)# speed 10
Switch(config-if)# duplex half
This example shows how to set the interface speed to 100 Mb/s on a 10/100/1000 Mb/s port:
Switch# configure terminal
Switch(config)# interface gigabitethernet1/0/2
Switch(config-if)# speed 100
Configuring IEEE 802.3x Flow Control
Flow control enables connected Ethernet ports to control traffic rates during congestion by allowing
congested nodes to pause link operation at the other end. If one port experiences congestion and cannot
receive any more traffic, it notifies the other port by sending a pause frame to stop sending until the
condition clears. Upon receipt of a pause frame, the sending device stops sending any data packets,
which prevents any loss of data packets during the congestion period.
Note Catalyst 3750-X or 3560-X ports can receive, but not send, pause frames.
You use the flowcontrol interface configuration command to set the interface’s ability to receive pause
frames to on, off, or desired. The default state is off.
Step 4
duplex {auto | full | half} This command is not available on a 10-Gigabit Ethernet interface.
Enters the duplex parameter for the interface.
Enables half-duplex mode (for interfaces operating only at 10 or
100 Mb/s). You cannot configure half-duplex mode for interfaces
operating at 1000 Mb/s.
You can configure the duplex setting when the speed is set to auto.
For more information about duplex settings, see the “Speed and
Duplex Configuration Guidelines” section on page 1-31.
Step 5
end Returns to privileged EXEC mode.
Step 6
show interfaces interface-id Displays the interface speed and duplex mode configuration.
Step 7
copy running-config startup-config (Optional) Saves your entries in the configuration file.
Command Purpose
