Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring Interface Characteristics
Configuring the Cisco eXpandable Power System (XPS) 2200
You use the switch CLI to configure the XPS:
• Configuring the System Names, page 1-49
• Configuring XPS Ports, page 1-50
• Configuring XPS Power Supplies, page 1-51
Configuring the System Names
To configure a name for the XPS 2200 system and for an XPS port connected to a switch, follow these
steps beginning in privileged EXEC mode:
Use the no power xps switch-number name command to remove the system name. Use the no power
xps switch-number port command to remove the port name.
Command Purpose
Step 1
configure terminal Enters global configuration mode.
Step 2
power xps switch-number name {name |
serialnumber}
Configures a name for the XPS 2200 system.
• name—Enter a name for the XPS 2000 port. The name can have up
to 20 characters.
• serialnumber—Use the serial number of the XPS 2200 as the system
name.
The switch-number appears only on Catalyst 3750-X switches and
represents the switch number in the data stack, a value from 1 to 9.
Step 3
power xps switch-number port {name |
hostname | serialnumber}
Configures a name for an XPS 2200 port connected to the switch.
• name—Enter a name for the XPS 2000 port.
• hostname—Use the hostname of the switch connected to the port.
• serialnumber—Use the serial number of the switch connected to the
port.
The switch-number appears only on Catalyst 3750-X switches and
represents the switch number in the data stack, a value from 1 to 9.
Step 4
end Returns to privileged EXEC mode.
Step 5
show env xps system Verifies the configured name of the system and ports.
Step 6
copy running-config startup-config (Optional) Saves your entries in the configuration file.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
