Chapter 1 Configuring Port-Based Traffic Control
Configuring Port Security
VLAN, but is not learned on the access VLAN. If you connect a single PC to the Cisco IP phone,
no additional MAC addresses are required. If you connect more than one PC to the Cisco IP phone,
you must configure enough secure addresses to allow one for each PC and one for the phone.
• When a trunk port configured with port security and assigned to an access VLAN for data traffic and
to a voice VLAN for voice traffic, entering the switchport voice and switchport priority extend
interface configuration commands has no effect.
When a connected device uses the same MAC address to request an IP address for the access VLAN
and then an IP address for the voice VLAN, only the access VLAN is assigned an IP address.
• When you enter a maximum secure address value for an interface, and the new value is greater than
the previous value, the new value overwrites the previously configured value. If the new value is less
than the previous value and the number of configured secure addresses on the interface exceeds the
new value, the command is rejected.
• The switch does not support port security aging of sticky secure MAC addresses.
Table 1-3 summarizes port security compatibility with other port-based features.
Table 1-3 Port Security Compatibility with Other Switch Features
Type of Port or Feature on Port Compatible with Port Security
DTP
1
port
2
1. DTP = Dynamic Trunking Protocol
2. A port configured with the switchport mode dynamic interface configuration command.
No
Trunk port Yes
Dynamic-access port
3
3. A VLAN Query Protocol (VQP) port configured with the switchport access vlan dynamic interface configuration command.
No
Routed port No
SPAN source port Yes
SPAN destination port No
EtherChannel Yes
Tunneling port Yes
Protected port Yes
IEEE 802.1x port Yes
Voice VLAN port
4
4. You must set the maximum allowed secure addresses on the port to two plus the maximum number of secure addresses
allowed on the access VLAN.
Yes
Private VLAN port No
IP source guard Yes
Dynamic Address Resolution Protocol (ARP) inspection Yes
Flex Links Yes

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
