1-9
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring LLDP, LLDP-MED, and Wired Location Service
Configuring LLDP, LLDP-MED, and Wired Location Service
Use the no form of each command to return to the default setting.
This example shows how to configure VLAN 100 for voice application with CoS and to enable the
network-policy profile and network-policy TLV on an interface:
Switch# configure terminal
Switch(config)# network-policy profile 1
Switch(config-network-policy)# voice vlan 100 cos 4
Switch(config)# exit
Switch# configure terminal
Switch# interface_id
Switch(config-if)# network-policy 1
Switch(config-if)# lldp med-tlv-select network-policy
This example shows how to configure the voice application type for the native VLAN with priority
tagging:
Switch(config-network-policy)# voice vlan dot1p cos 4
Switch(config-network-policy)# voice vlan dot1p dscp 34
Step 3
{voice | voice-signaling} vlan [vlan-id
{cos cvalue | dscp dvalue}] | [[dot1p
{cos cvalue | dscp dvalue}] | none |
untagged]
Configure the policy attributes:
voice—Specify the voice application type.
voice-signaling—Specify the voice-signaling application type.
vlan—Specify the native VLAN for voice traffic.
vlan-id—(Optional) Specify the VLAN for voice traffic. The range is
1 to 4094.
cos cvalue—(Optional) Specify the Layer 2 priority class of service
(CoS) for the configured VLAN. The range is 0 to 7; the default is 5.
dscp dvalue—(Optional) Specify the differentiated services code
point (DSCP) value for the configured VLAN. The range is 0 to 63;
the default is 46.
dot1p—(Optional) Configure the telephone to use IEEE 802.1p
priority tagging and use VLAN 0 (the native VLAN).
none—(Optional) Do not instruct the IP telephone about the voice
VLAN. The telephone uses the configuration from the telephone key
pad.
untagged—(Optional) Configure the telephone to send untagged
voice traffic. This is the default for the telephone.
Step 4
exit Return to global configuration mode.
Step 5
interface interface-id Specify the interface on which you are configuring a network-policy
profile, and enter interface configuration mode.
Step 6
network-policy profile number Specify the network-policy profile number.
Step 7
lldp med-tlv-select network-policy Specify the network-policy TLV.
Step 8
end Return to privileged EXEC mode.
Step 9
show network-policy profile Verify the configuration.
Step 10
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
