Chapter 1 Configuring SPAN and RSPAN
Configuring SPAN and RSPAN
To delete a SPAN session, use the no monitor session session_number global configuration command.
To remove a source port or VLAN from the SPAN session, use the no monitor session session_number
source {interface interface-id | vlan vlan-id} global configuration command. To remove the RSPAN
VLAN from the session, use the no monitor session session_number destination remote vlan vlan-id.
This example shows how to remove any existing RSPAN configuration for session 1, configure RSPAN
session 1 to monitor multiple source interfaces, and configure the destination as RSPAN VLAN 901.
Switch(config)# no monitor session 1
Switch(config)# monitor session 1 source interface gigabitethernet1/0/1 tx
Switch(config)# monitor session 1 source interface gigabitethernet1/0/2 rx
Switch(config)# monitor session 1 source interface port-channel 2
Switch(config)# monitor session 1 destination remote vlan 901
Switch(config)# end
Specifying VLANs to Filter
Beginning in privileged EXEC mode, follow these steps to configure the RSPAN source session to limit
RSPAN source traffic to specific VLANs:
Step 6
show monitor [session session_number]
show running-config
Verify the configuration.
Step 7
copy running-config startup-config (Optional) Save the configuration in the configuration file.
Command Purpose
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
no monitor session {session_number | all |
local | remote}
Remove any existing SPAN configuration for the session.
For session_number, the range is 1 to 66.
Specify all to remove all SPAN sessions, local to remove all local
sessions, or remote to remove all remote SPAN sessions.
Step 3
monitor session session_number source
interface interface-id
Specify the characteristics of the source port (monitored port) and
SPAN session.
For session_number, the range is 1 to 66.
For interface-id, specify the source port to monitor. The interface
specified must already be configured as a trunk port.
Step 4
monitor session session_number filter vlan
vlan-id [, | -]
Limit the SPAN source traffic to specific VLANs.
For session_number, enter the session number specified in step 3.
For vlan-id, the range is 1 to 4094.
(Optional) Use a comma (,) to specify a series of VLANs or use a
hyphen (-) to specify a range of VLANs. Enter a space before and after
the comma; enter a space before and after the hyphen.
